Acrylic Diffuser Extruded Sheet Mainly used as the outer shell of LED lamp, DIY lamp, office lamp, kitchen lamp and fluorescent lamp. The polycarbonate light diffuser can evenly diffuse the light spots on the surface to obtain soft and comfortable light
1, Light Transmission: Normally 90%、85%、80%、76%、60%, can tailor to customer’s requirements
2, Appearance: One side matte, another side smooth;one side matte, another side orange peel texture;
3 ,Outstanding LED Hiding Ability
4, Easy To Fabricate
5, Environment Friendly
6, OEM/ODM Customizable
DESCRIPTION
Excellent Selection Of 100% Virgin Material & Unique Formula
Base on the optical theory, the Led diffusion sheet is produced with Optical grade PMMA raw material and scientific formula processing, the light can be reflected and refracted and scattering in the chemistry particles and resin continuously to achieve the best light transmission and excellent Led hiding ability and Increases light uniformity throughout the lighting diffuser
Excellent Optic Diffusion Performance & Efficiency
LED Lighting Diffuser enable high efficiency extraction of light from a luminaire without sacrificing performance. Transmission well in excess of 90% is typical, and luminaire dependent efficiency can be even higher.
Strong illuminant Hiding Ability
Lighting diffuser offer outstanding hiding of LED and fluorescent light sources, with excellent color mixing. The diffuser solve the most difficult LED hiding problems while maintaining excellent efficiency.
Matte surface & Orange Peel Texture
Matte Surface for one side or Orange Peel Texture side specifically designed for LED panel light, downlight and so on, it features a unique combination of high light diffusion and high light transmission through a combination of optimized surface texture and advanced diffuser technologies. Increases light uniformity throughout the lighting diffuser;
Application:
LEDs are long-lasting, energy-efficient light sources. However, LEDs are particularly challenging for lighting designers because they create "hot spots" of focused light, which reduce the visual appeal of the luminaire. Special grades of acrylic sheet, polycarbonate sheet and diffuser acrylic sheet have been carefully designed to diffuse LED hot spots without sacrificing light transmission, and have excellent LED light diffusing characteristics.
To order diffuser acrylic sheets, simply fill in the form below with any and all special requests for diffuser acrylic sheets and we will get back to you within 24h with a professional response.
Our diffuser sheet being widely used for the panel light, Down light, linear light and so on, that's because our diffuser sheet with different levels of light diffusion to meet various fixture performance requirements. "Some designs, for example, may want a low level of diffusion to soften the edges of emitted light. Others may need more light diffusion to reduce direct glare. Also, variables such as the LED-to-lens distance and the LED matrix spacing affect the optimal light diffusion. While diffusion and light transmission are directly associated, having these diffusion options allows the light fixture designer the ability to achieve the lighting qualities they desire for a specific fixture."
For Back-lit Led Luminaire:
Code | Thickness | Appearance | Distance between lamps: working distance to diffuser | Transmission (Test by Transmission and haze Analyzer, ASTM D1003-61(1997) | Efficiency in typical LED luminaire | Commends | |
JK-90 | 2mm | One side matt, Another side smooth or orange peel texture | 1:2 | 92% | 92%-95% | Highest efficiency, Good lamp hiding | |
JK-85 | 1.5mm | One side matt, Another side smooth or both side matt | 1:2.5 | 88% | 88%-92% | Excellent efficiency, Increased lamp hiding | |
JK-76 | 1.5mm | One side matt, Another side smooth or both side matt | 1:2 | 85% | 85%-88% | High efficiency, Excellent lamp hiding | |
JK-60 | 2mm | One side matt, Another side orange peel texture | 1:1.5 | 80% | 80%-85% | General efficiency, Strongest lamp hiding available |
For side lighting Led Luminaire:
Code | Thickness | Appearance | Recommend Light Guide Plate | Transmission (Test by Transmission and haze Analyzer, ASTM D1003-61(1997) | Efficiency in typical LED luminaire | Commends |
JK-90 | 1.5mm | One side matt, Another side orange peel texture | Screen printed LGP | 93% | 90%-93% | Highest efficiency, General defect hiding |
JK-85 | 1.5mm | One side matt, Another side smooth or both side matt | Screen printed or Laser cutting LGP | 88% | 88%-92% | Excellent efficiency, Increased defect hiding |
JK-76 | 1.5mm | One side matt, Another side smooth or both side matt | Screen printed or Laser cutting LGP | 85% | 85%-88% | Excellent efficiency, Strongest defect hiding |
